Specification
| Brand | Cisco Systems Inc |
| Model | ASR1002 |
| Part Number | Cisco ASR1002 ESP5 |
General
| Device Type | Router |
| Interface (Buy) Type | 3 integrated 10/100/1000 Ethernet ports with 1 port capable of RJ-45 or SFP connectivity |
Performance
| RAM | 4-GB DRAM shared across RP and SIP |
| Flash Memory | 1-GB USB flash-memory support |
Form Factor
| Form Factor | Rack-mountable - 2U |
EXPANSION / CONNECTIVITY
| Expansion Slots |
Shared port adapters 3 SPA slots Cisco ASR 1000 Series ESP 1 ESP slot Route Processor Integrated in chassis Number of SIPs or Ethernet Line Cards Supported Integrated in chassis Redundancy Software: Yes Built-in 10 Gigabit Ethernet Port No Network Interface Module No Integrated daughter card (IDC) No Airflow Front-to-back SP support Cisco ASR 1000 Series 5-Gbps ESP (ASR1000-ESP5), Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10), and noncrypto Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10-N) |
| Interfaces | Wired |
DIMENSIONS & WEIGHT
| dimensions ( H x W x D) |
Height: 3.5 in. (88.9 mm) Width: 17.2 in. (437.4 mm) Depth: 18.15 in. (461.0 mm) Weight: |
| Weight | 33.65 lb (15.23 kg) (with dual AC power supply and SPA blank covers) |
NETWORKING
| Ports | 4 Gigabit Ethernet Small Form-Factor Pluggable (SFP) ports |
| Connectivity Technology | Wired |
| Data Link Protocol | 10/100/1000Base-T(X) |
| Data Transfer Rate | ESP bandwidth 5 to 10 Gbps |
MISCELLANEOUS
| Mix Features |
ESP support Cisco ASR 1000 Series 5-Gbps ESP (ASR1000-ESP5), Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10), and non-crypto Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10-N) |
POWER
| Power Options |
Dual power supplies by default; option of either AC or DC power supply Note: A mix of one AC and one DC power supply is not supported. |
SERVICE & SUPPORT
| Warranty | limited 01-month warranty |
